Processing Materials: Limestone ball mill is widely applied in the industries such as cement plants, quarry, power plants, new materials, refractory materials and other production fields. It's mainly used for grinding river pebbles, pebbles, gypsum, limestone, basalt, etc. Using ball mill to produce limestone powder not only reduces the cost, but also has less environmental pollution, and can create high benefits for enterprises.
Technical Parameters
Model | Ball loading (t) | Feed size(мм) | Size | Performance engine power (kw) | Weight |
Ф900×1800 | 1.4 | ≤20 | 0.075-0.89 | 18.5 | 3.6 |
Ф900×2100 | 1.7 | ≤15 | 0.075-0.83 | 15 | 3.9 |
Ф900×3000 | 2.7 | ≤20 | 0.075-0.89 | 22 | 4.5 |
Ф1200×2400 | 3.5 | ≤25 | 0.075-0.6 | 30 | 11.5 |
Ф1200×2800 | 6.8 | ≤25 | 0.075-0.6 | 37 | 13 |
Ф1200×4500 | 5.5 | ≤25 | 0.074-0.4 | 55 | 13.8 |
Ф1500×3000 | 6.8 | ≤25 | 0.074-0.4 | 75 | 17 |
Ф1500×4500 | 10.5 | ≤25 | 0.074-0.4 | 110 | 21 |
Ф1500×5700 | 15 | ≤25 | 0.074-0.4 | 130 | 24.7 |
Ф1830×3000 | 13 | ≤25 | 0.074-0.4 | 160 | 28 |
Ф1830×3600 | 15 | ≤25 | 0.075-0.4 | 160 | 33.5 |
Ф1830×4500 | 17 | ≤25 | 0.075-0.6 | 185 | 35 |
Ф1830×7000 | 25 | ≤25 | 0.074-0.4 | 210 | 36 |
Ф2100×3600 | 21 | ≤25 | 0.074-0.4 | 185 | 46.8 |
Ф2200×5500 | 30 | ≤25 | 0.074-0.4 | 245 | 48.5 |
Ф2200×6500 | 35 | ≤25 | 0.074-0.4 | 380 | 52.8 |
Ф2200×7500 | 33 | ≤25 | 0.074-0.4 | 380 | 56 |
Ф2400×3000 | 30 | ≤25 | 0.075-0.4 | 245 | 59 |
Ф2400×4500 | 33 | ≤25 | 0.074-0.4 | 380 | 65 |
Ф2700×3600 | 39 | ≤25 | 0.074-0.4 | 400 | 91.3 |
Ф2700×4000 | 40 | ≤25 | 0.074-0.4 | 400 | 94 |
Ф2700×4500 | 48 | ≤25 | 0.074-0.4 | 430 | 102 |
Ф3200×4500 | 65 | ≤25 | 0.075-0.4 | 800 | 137 |
Ф3600×4500 | 90 | ≤25 | 0.074-0.4 | 850 | 158 |
Ф3600×6000 | 110 | ≤25 | 0.074-0.4 | 1250 | 175 |
Ф3600×8500 | 131 | ≤25 | 0.074-0.4 | 1800 | 252 |
Ф4000×5000 | 121 | ≤25 | 0.074-0.4 | 1500 | 203 |
Ф4000×6000 | 146 | ≤25 | 0.074-0.4 | 1600 | 218 |
Introduction of Limestone Ball Mill
Limestone ball mill is the key equipment for limestone regrinding, which has the advantages of stable operation, good grinding effect, low energy consumption, good environmental performance and less pollution. Nile Machinery can provide customized production of limestone ball grinding mill. According to the characteristics of limestone and daily operation requirements of users, the company can configure suitable limestone grinding ball mill for users within the production budget of users, which can help users bring higher production benefits.
Advantages of Limestone Ball Mill
1.Limestone sand ball mill adopts rolling bearing instead of sliding bearing, which reduces production resistance and improves operation efficiency and service life of bearing.
2.Limestone ball milling has novel structure and stable performance, which is suitable for mixing and grinding of ordinary and special materials.
3.The ball mill equipment has a very good sealing performance, the grinding process is in the negative pressure state and the finished limestone product has very high purity.
4.The user can choose a suitable limestone ball milling machine according to the characteristics of the limestone. The type of lining plate is optional, which can be rough grinding or fine grinding.
5.The operation of the whole grinding machine is more stable, the energy consumption of the equipment in the operation is lower, and the operation cost is lower.
6. The limestone ball grinding mill machine can work continuously, the processing capacity of limestone in unit time is stronger, and the output of the equipment is larger.
Technical Parameters of Limestone Ball Mill
Model | Ball loading (t) | Feed size(мм) | Size | Performance engine power (kw) | Weight |
Ф900×1800 | 1.4 | ≤20 | 0.075-0.89 | 18.5 | 3.6 |
Ф900×2100 | 1.7 | ≤15 | 0.075-0.83 | 15 | 3.9 |
Ф900×3000 | 2.7 | ≤20 | 0.075-0.89 | 22 | 4.5 |
Ф1200×2400 | 3.5 | ≤25 | 0.075-0.6 | 30 | 11.5 |
Ф1200×2800 | 6.8 | ≤25 | 0.075-0.6 | 37 | 13 |
Ф1200×4500 | 5.5 | ≤25 | 0.074-0.4 | 55 | 13.8 |
Ф1500×3000 | 6.8 | ≤25 | 0.074-0.4 | 75 | 17 |
Ф1500×4500 | 10.5 | ≤25 | 0.074-0.4 | 110 | 21 |
Ф1500×5700 | 15 | ≤25 | 0.074-0.4 | 130 | 24.7 |
Ф1830×3000 | 13 | ≤25 | 0.074-0.4 | 160 | 28 |
Ф1830×3600 | 15 | ≤25 | 0.075-0.4 | 160 | 33.5 |
Ф1830×4500 | 17 | ≤25 | 0.075-0.6 | 185 | 35 |
Ф1830×7000 | 25 | ≤25 | 0.074-0.4 | 210 | 36 |
Ф2100×3600 | 21 | ≤25 | 0.074-0.4 | 185 | 46.8 |
Ф2200×5500 | 30 | ≤25 | 0.074-0.4 | 245 | 48.5 |
Ф2200×6500 | 35 | ≤25 | 0.074-0.4 | 380 | 52.8 |
Ф2200×7500 | 33 | ≤25 | 0.074-0.4 | 380 | 56 |
Ф2400×3000 | 30 | ≤25 | 0.075-0.4 | 245 | 59 |
Ф2400×4500 | 33 | ≤25 | 0.074-0.4 | 380 | 65 |
Ф2700×3600 | 39 | ≤25 | 0.074-0.4 | 400 | 91.3 |
Ф2700×4000 | 40 | ≤25 | 0.074-0.4 | 400 | 94 |
Ф2700×4500 | 48 | ≤25 | 0.074-0.4 | 430 | 102 |
Ф3200×4500 | 65 | ≤25 | 0.075-0.4 | 800 | 137 |
Ф3600×4500 | 90 | ≤25 | 0.074-0.4 | 850 | 158 |
Ф3600×6000 | 110 | ≤25 | 0.074-0.4 | 1250 | 175 |
Ф3600×8500 | 131 | ≤25 | 0.074-0.4 | 1800 | 252 |
Ф4000×5000 | 121 | ≤25 | 0.074-0.4 | 1500 | 203 |
Ф4000×6000 | 146 | ≤25 | 0.074-0.4 | 1600 | 218 |
